What is Aluminum Beam?
Aluminum Beams are prefabricated core scaffolding components widely used for multiple construction applications, including building bridge decks within scaffold frames, setting up suspended work platforms, and constructing temporary overhead shelters. All raw aluminum profiles are processed via laser cutting, precision punching and arc trimming, keeping component tolerance under 0.2mm. Every joint is double-welded by skilled workers with years of experience in aluminum truss fabrication, which guarantees solid welding quality and minimizes structural deformation. Our factory-made aluminum beams are well-received by clients from Australia, the UK, Ireland and many other overseas markets.
Aluminum Beam Production Process
Aluminum beams are widely used in construction, scaffolding, and industrial applications due to their lightweight strength and corrosion resistance. At Superman Scaffold, we follow a strict and efficient production process to ensure every aluminum beam meets international standards and customer expectations.
Production Process Overview
- Lightweight & High Load Capacity: The aluminum beam features light dead weight while delivering outstanding bearing performance, effectively reducing overall scaffold load.
- Superior Corrosion Resistance: Natural anti-rust property makes it perfectly suitable for outdoor construction and coastal marine projects.
- Fully Customizable: Support customized beam profiles, dimensions and surface finishes to match diverse scaffolding project demands.
- Precision Machining: Adopts advanced extrusion, laser cutting and strict inspection procedures to guarantee uniform dimensional accuracy and stable product quality.
- Eco-Friendly Material: Aluminum material is 100% recyclable, with low energy consumption during processing.
Type of aluminum beam
Aluminum Lattice Beam
Premium aluminum lattice beams matched for 48.3mm tube & fitting scaffolding systems. Delivering reliable structural performance without compromise, aluminum beams cut costs compared to steel alternatives. Far lighter than steel equivalents, they speed up site assembly and reduce overall construction labour time.
- Optimized design for quick assembly with couplers to all standard scaffolding frames
- Weighs less than half of an equivalent steel beam
- Higher load capacity, up to 1.5 times stronger than steel beams of the same size
- Fully tested and certified to meet European construction standards
- Secure joint connection via 4-bolt spigot system
- Standard lengths in stock: 1m, 2m, 3m, 4m, 6m; custom sizes available on request
Specification | Material & Thickness | Net Weight |
914*490 | 6063-T5 Aluminum, 2.0mm | 7.9kg |
1219*490 | 6063-T5 Aluminum, 2.0mm | 10.1kg |
1524*490 | 6063-T5 Aluminum, 2.0mm | 11.7kg |
1829*490 | 6063-T5 Aluminum, 2.0mm | 14kg |
2134*490 | 6063-T5 Aluminum, 2.0mm | 16.2kg |
2438*490 | 6063-T5 Aluminum, 2.0mm | 18kg |
Aluminum Beam Pack and Ship
Every aluminum beam is elaborately packed before shipment to guarantee intact, scratch-free delivery. We fully recognize that surface finish and precise dimensions must be well protected during transit, so all packaging and logistics steps are implemented under rigorous standard specifications.
- Protective Packaging – Each beam is wrapped with protective film, fixed with foam or wooden brackets to avoid surface scratches and bending deformation.
- Customized Pallet Loading – Beams are neatly stacked and firmly strapped on solid wooden or steel pallets for stable loading and transport.
- Weatherproof Protection – Waterproof wrapping and sealed outer layers keep beams dry and clean during long-distance sea or land shipping.
- Efficient Logistics – We cooperate with trusted freight suppliers to ensure on-time, damage-free delivery worldwide.
- Global Export Packing – Our export packaging meets international shipping norms and can be customized according to buyers’ special demands.
